Hybrid Electric Vehicle (HEV)

Governments are asking the public to reduce fuel consumption and lower pollution. They do this without imposing a change in driving habits and the HEV fits the bill. Japan is leading in adapting the HEV because of high fuel costs and environmental concerns.

The purpose of the HEV is to conserve fuel without sacrificing performance, and the HEV achieves this by using one or several electric motor to assist the ICE during acceleration and to harness kinetic energy when braking. The ICE turns off at traffic lights and the electric motor propels the car through slow-moving traffic. On full power, both the ICE and electric motor engage for optimal acceleration.

The HEV uses a mechanical powertrain to transfer power from the ICE to the wheels. In this respect, the HEV resembles an ordinary vehicle with a crankshaft and a clutch, also known as parallel configuration. Fuel savings are achieved by the use of a smaller ICE that is tuned for maximum fuel efficiency rather than high torque. Toyota claims a thermal efficiency of 40 percent for the new Prius. Peppy driving is accredited to the electric motor as this propulsion system delivers far better torque than a sluggish ICE of the same horsepower. Figure 1 illustrates the different modes of an electrified powertrain in in an HEV.

HEV Battery

Figure 1: Basic function or an electrified powertrain in an HEV.
Battery power is only used for short durations. The HEV battery seldom encounters full charge-discharge cycles that are common in the electric vehicle.
Source: RWTH Aachen University, Germany

Most batteries for HEVs are guaranteed for 8 years. To meet this long service life, the cells are optimized for longevity rather than high specific energy as with consumer products. The battery maker achieves this in part by using a thicker and more durable separator. To reduce stress, the battery operates at 30–80 percent state-of-charge (SoC), or roughly 3.5–4.0V/cell for Li-ion, rather than the customary 3.0–4.20V/cell.

HEV batteries operate momentarily and share similarity with a starter battery by applying short power bursts for acceleration rather than long, continuous discharges as with the EV. Rarely will an HEV battery discharge to a low 20 percent state-of-charge (SoC). Under normal use, a parallel HEV consumes less than 2 percent of the available battery capacity per mile (1.6km). Capacity fade goes unnoticed, and an HEV battery still works well with less than half the original capacity.

Figure 2 shows the battery capacity of six hybrid cars at a 256,000km (160,000 miles). The test was done by the US Department of Energy’s FreedomCAR and Vehicle Technologies Program (FCVT) in 2006 according to SAE J1634 practices and it included the Honda Civic, Honda Insight and Toyota Prius.

Untitled

Figure 2: End-of-life battery capacity of HEVs. At 256,000km (160,000 miles), the two Honda Civic vehicles had 68% capacity, the Insight had 85% and the Prius had 39%. The capacity fade did not affect the fuel efficiency by much.
Source: FreedomCAR and Vehicle Technologies Program

The hybrid battery of the two Honda Civic vehicles had 68 percent remaining capacity; the Insight had 85 percent and the Prius 39 percent. Even with lower capacity at the end of life, the fuel efficiency was not severely affected. The Insight showed a 1.2mpg (0.12L/km) decrease in fuel economy during the test, while the Prius reduced the fuel efficiency by 3.2mpg (0.33L/km). Air-conditioning was off in both cases.

Stringent battery demands are needed for hybrid trucks with a gross vehicle weight of 33 tons (73,000 lb). The battery must be able to continuously charge and discharge at 4C, deliver 10kW (200hp) for up to 10 minutes, operate at –20°C to 40°C (–4°F to 104°F) and deliver 5 years of service. Supercapacitors would provide the required durability but high cost and low energy density are against this choice. Lead acid has good discharge characteristics but it is slow to charge. Li-ion, especially LTO, would be a good choice but high power draw requires active cooling. Second generation NiMH is being tested; the rugged NiCd may also be tried.

Paradox of the hybrid vehicle

As good as a hybrid may be, the car is not without ironies. At a conference addressing advanced automotive batteries, an HEV opponent argued with an HEV maker that a diesel car offers better fuel economy than a hybrid. Being a good salesman, the HEV maker flatly denied the claim. Perhaps both are right. In city driving, the HEV clearly delivers better fuel-efficiency while diesel consumes less on the highway. Combining both would provide the best solution, but the high cost of a diesel-hybrid solution might not pay back with low fuel prices, although such vehicles are available in Europe.

High-end HEVs come with a full-sized ICE of 250hp and an electrical motor of 150–400hp in total. Such vehicles will surely find buyers, especially if the government assists with grants for being “green.” It’s unfortunate that consumers who walk, cycle or take public transportation won’t get such handouts. Common sense reminds us to conserve energy by driving less, or using smaller vehicles when driving is necessary.

Wolfgang Hatz, the then head of powertrain for Volkswagen Group, said that hybrid technology is a very expensive way to save a small amount of fuel and states that Volkswagen only makes hybrids because of political pressure. He supports diesel as the most energy-efficient motor, especially on highways.

Volkswagen may have a solution — the 1-Liter Car (Figure 3). It is called the 1-Liter Car because the concept vehicle burns only one liter of fuel per 100km. To prove the concept, the then VW chairman Dr. Ferdinand Piëch drove the car from their headquarters in Wolfsburg to Hamburg for a shareholders meeting. The average consumption was just 0.89 liters per 100km (317mpg).

Figure 3: Volkswagen’s 1-Liter Car. The 1-Liter Car is said to be the most economical car in the world but it never made it into production.
Source: Volkswagen AG

Aerodynamics and weight help to achieve the low fuel consumption. While a typical car has a drag coefficient of 0.30, the 1-Liter Car is only 0.16. Carbon fiber and a magnesium frame reduce the weight to 290kg (640lb). The one-cylinder diesel engine generates 8.5hp (6.3kW), and the 6.5-litre (1.43-gallon) fuel tank has a range of 650 kilometers (400 miles). The average fuel consumption is 0.99 liter per 100km (238mpg).

Although the 1-Liter Car did not go into production, VW demonstrated that fossil fuel could be stretched should the cost rise or should frivolous consumption create unsustainably high pollution levels. Point-to-point personal transportation could be made possible with a light carrier that weighs only 290kg, a weight that is less than the 540kg Tesla S battery. Rather than consuming 150–250Wh per kilometer, as with an electric vehicle, the 1-Liter Car would only use about 40Wh/km. Even though it burns fossil fuel, the environmental impact would be less than an EV propelled with electricity, which is mainly produced by fossil fuel.

Plug-in Hybrid Electric Vehicle (PHEV)

Most PHEVs use a fully electrified powertrain in a series configuration with no mechanical linkage from ICE to wheels. The system runs solely on the electric motor for propulsion, and the ICE only engages when the batteries get low to supply electricity for the electric motor and to charge the battery. The driving range of a fully charged battery is about 50km (30 miles).

The PHEV is ideal for commuting and doing errands. No gasoline is consumed when driving on batteries and the highways are tax-free. However, there will be an increase in the electrical utility bill to charge the batteries at home.

Unlike the parallel HEV that relies on the battery for only brief moments, the PHEV battery is in charge depletion mode, meaning that the battery must work harder than on an HEV. This adds to battery stress and reduces longevity. While a capacity drop to 39 percent will affect the performance of the Toyota Prius HEV only marginally, such a loss would reduce the electric driving range of a PHEV from 50km to 20km (30 to 12 miles).

The Chevy Volt carries a 16kWh Li-ion battery that weighs 181kg (400 lb) and powers a 149hp (111kW) electric motor. The temperature of the prismatic cells is kept at 20–25C (68–77F) during charging and driving. An 115VAC outlet fills the battery in 8 hours; a 230VAC reduces the charging time to 3 hours. The driving range is 64km (40 miles) before the 1.4-liter four-cylinder ICE kicks in to activate the 53kW AC generator that powers the electric motors.

Economics

As good as the PHEV sounds, the long-term savings may be smaller than expected, especially if a battery replacement is needed during the life of the car. Battery aging is an issue that car makers avoid mentioning in fear of turning buyers away. A motorist used to driving ICE cars expects ample power at hot and cold temperatures and minimal performance degradation with age. The battery cannot match this fully, and the owner will need to tolerate a decrease in driving range during the winter, as well as accept a small reduction in delivered mileage with each advancing year due to battery aging.

Modern cars do more than provide transportation; they also include amenities for safety, comfort and pleasure. The most basic of these are the headlights and windshield wipers. Buyers also want cabin heat and air-conditioning, services that are taken for granted in a vehicle that burns fossil fuel. Heat is a by-product in the ICE that must be generated with battery power in a PHEV, but the larger concern is air-conditioning, which draws 3–5kW of power. Comforts might need to be provided more sparingly when running on a battery.

Many PHEV buyers value the environmental benefit and the pleasure of driving a quiet vehicle powered by electricity. This has a large buyer appeal because electric propulsion is more natural than that of an ICE. Drivers must adapt to the new lifestyle of charging the vehicle at night when electricity is cheap and then driving measured distances. Users of these cars will also appreciate new charging stations at workplaces and shopping malls.

,

How Low can a Battery be Discharged?

Data trend chart - Gsm-Discharges-Liion

Discover what causes short runtimes

Not all battery energy can or should be used on discharge; some reserve is almost always left behind on purpose after the equipment cuts off. There are several reasons for this.

Most mobile phones, laptops and other portable devices turn off when the lithium-ion battery reaches 3.00V/cell on discharge. At this point the battery has about 5 percent capacity left. Manufacturers choose this voltage threshold to preserve some energy for housekeeping, as well as to reduce battery stress and allow for some self-discharge if the battery is not immediately recharged. This grace period in empty state can last several months until self-discharge lowers the voltage of Li-ion to about 2.50V/cell, at which point the protection circuit opens and most packs become unserviceable with a regular charger.

Power tools and medical devices drawing high current tend to push the battery voltage to an early cut-off prematurely. This is especially apparent at cold temperatures and in cells with high internal resistance. These batteries may still have ample capacity left after the cutoff; discharging them with a battery analyzer at a moderate load will often give a residual capacity of 30 percent. Figure 1 illustrates the cut-off voltage graphically.

Figure 1: Illustration of equipment with high cut-off voltage.

Portable devices do not utilize all available battery power and leave some energy behind.



To prevent triggering premature cutoff at a high load or cold temperature, some device manufacturers may lower the end-of-discharge voltage. Li-ion in a power tool may discharge the battery to 2.70V/cell instead of 3.00V/cell; Li-phosphate may go to 2.45V/cell instead of 2.70V/cell, lead acid to 1.40V/cell instead of the customary 1.75V/cell, and NiCd/NiMH to 0.90V/cell instead of 1.00V/cell.

Industrial applications aim to attain maximum service life rather than optimize runtime, as it is done with consumer products. This also applies to the electric powertrain; batteries in a hybrid cars and electric vehicle electric vehicles are seldom fully discharged or charged; most operate between 30 and 80 percent state-of-charge when new. This is the most effective working bandwidth; it also delivers the longest service life. A deep discharge to empty followed a full charge would cause undue stress for the Li-ion. Similarly, satellitesuse only the mid-band of a battery called the “sweet zone.” Figure 2 illustrates the “sweet zone” of a battery.

Figure 2: Sweet zone of a Lithium-ion battery to extend life.

Operating Li-ion in the “sweet zone” prolongs battery life because a partial cycle is less stressful than a full cycle. As the capacity fades with use, the battery management system (BMS) may engage the full working range of the battery.



Elevated internal resistance makes alkaline and other primary batteries unsuitable for high load applications. The resistance rises further as the cell depletes. This causes an early cutoff with the device drawing some current, and much energy is left behind. Primary batteries have high capacities and perform well when new, but they soon lose power like a deflating balloon.

,

How does Rising Internal Resistance affect Performance?

Equivalent_Full_Cycles Data trend chart

Understanding the importance of low conductivity

Capacity alone is of limited use if the pack cannot deliver the stored energy effectively; a battery also needs low internal resistance. Measured in milliohms (mΩ), resistance is the gatekeeper of the battery; the lower the resistance, the less restriction the pack encounters. This is especially important in heavy loads such as power tools and electric powertrains. High resistance causes the battery to heat up and the voltage to drop under load, triggering an early shutdown. Figure 1 illustrates a battery with low internal resistance in the form of a free-flowing tap against a battery with elevated resistance in which the tap is restricted.

low-Resistance

Low resistance, delivers high current on demand; battery stays cool.

 High-Resistance

High resistance, current is restricted, voltage drops on load; battery heats up.



Figure 1: Effects of internal battery resistance.

A battery with low internal resistance delivers high current on demand. High resistance causes the battery to heat up and the voltage to drop. The equipment cuts off, leaving energy behind.

Lead acid has a very low internal resistance and the battery responds well to high current bursts that last for a few seconds. Due to inherent sluggishness, however, lead acid does not perform well on a sustained high current discharge; the battery soon gets tired and needs a rest to recover. Some sluggishness is apparent in all batteries at different degrees but it is especially pronounced with lead acid. This hints that power delivery is not based on internal resistance alone but also on the responsiveness of the chemistry, as well as temperature. In this respect, nickel- and lithium-based technologies are more responsive than lead acid.

Sulfation and grid corrosion are the main contributors to the rise of the internal resistance with lead acid. Temperature also affects the resistance; heat lowers it and cold raises it. Heating the battery will momentarily lower the internal resistance to provide extra runtime. This, however, does not restore the battery and will add momentary stress.

Crystalline formation, also known as “memory,” contributes to the internal resistance in nickel-based batteries. This can often be reversed with deep-cycling. The internal resistance of Li-ion also increases with use and aging but improvements have been made with electrolyte additives to keep the buildup of films on the electrodes under control. With all batteries, SoC affects the internal resistance. Li-ion has higher resistance at full charge and at end of discharge with a big flat low resistance area in the middle.

Alkaline, carbon-zinc and most primary batteries have a relatively high internal resistance, and this limits their use to low-current applications such as flashlights, remote controls, portable entertainment devices and kitchen clocks. As these batteries deplete, the resistance increases further. This explains the relative short runtime when using ordinary alkaline cells in digital cameras.

Two methods are used to read the internal resistance of a battery: Direct current (DC) by measuring the voltage drop at a given current, and alternating current (AC), which takes reactance into account. When measuring a reactive device such as a battery, the resistance values vary greatly between the DC and AC test methods, but neither reading is right or wrong. The DC reading looks at pure resistance (R) and provides true results for a DC load such as a heating element. The AC reading includes reactive components and provides impedance (Z). Impedance provides realistic results on a digital load such as a mobile phone or an inductive motor.

Figure 2 illustrates the internal resistance of an 18650 Li-ion cell when exposed to 1,000 full cycles at 40ºC (104ºF). The AC readings in the green frame do not reflect the true resistive state of a battery; DC method provides more reliable performance data with loading.

Equivalent_Full_Cycles
Figure 2: Rise of internal resistances of 18650 Li-ion cell measured with AC and DC methods when cycled.
AC resistance readings in green frame stay low; DC method gives true state.
Source: Technische Universität München (TUM)

Pack Resistance

The internal resistance of a battery does not consist of the cells alone but also includes the interconnection, fuses, protection circuits and wiring. In most cases these peripherals more than double the internal resistance and can falsify rapid-test methods. Typical readings of a single cell pack for a mobile phone and a multi-cell battery for a power tool are shown below.

Internal Resistance of a Mobile Phone Battery

Cell, single, high capacity prismatic 50mΩ subject to increase with age
Connection, welded 1mΩ
PTC, welded to cable, cell 25mΩ 18–30 mΩ according to spec
Protection circuit, PCB 50mΩ
Total internal resistance ca. 130mΩ

Internal Resistance of a Power Pack for Power Tools

Cells 2P4S at 2Ah/cell, 18mΩ subject to increase with age
Connection, welded, each 0.1mΩ
Protection circuit, PCB 10mΩ
Total internal resistance ca. 80mΩ

Source: Siemens AG (2015, München)

Figures 3, 4 and 5 reflect the runtime of three batteries with similar Ah and capacities but different internal resistance when discharged at 1C, 2C and 3C. The graphs demonstrate the importance of maintaining low internal resistance, especially at higher discharge currents. The NiCd test battery comes in at 155mΩ, NiMH has 778mΩ and Li-ion has 320mΩ. These are typical resistive readings on aged but still functional batteries. That demonstrates the relationship of capacity, internal resistance and self-discharge.)

Gsm-Discharges-Nicd
Figure 3: GSM discharge pulses at 1, 2, and 3C with resulting talk-time
The capacity of the NiCd battery is 113%; the internal resistance is 155mΩ. 7.2V pack.



Gsm-Discharges-Nimh
Figure 4: GSM discharge pulses at 1, 2, and 3C with resulting talk-time
The capacity of the NiMH battery is 94%, the internal resistance is 778mΩ. 7.2V pack



Gsm-Discharges-Liion
Figure 5: GSM discharge pulses at 1, 2, and 3C with resulting talk-time
The capacity of the Li-ion battery is 107%; the internal resistance is 320mΩ. 3.6V pack

Notes: The tests were done when early mobile phones were powered by NiCd, NiMH and Li-ion. Li-ion and NiMH have since improved.

The maximum GSM draws is 2.5A, representing 3C from an 800mAh pack, or three times the rated current.

, ,

How to Define Battery Life

Data trend chart - How to Define Battery Life

Become familiar with battery fade and how the ready light can deceive the user.

Folks have been using rechargeable batteries for over 100 years but this marvelous power source is still poorly understood. The battery is a silent worker that delivers energy until it quits of exhaustion and old age. It is more prone to failure than most other parts in a system. Much is expected but little is given in return. With a shorter life span than the host device, battery replacement becomes an issue, and the “when” and “what if” are not well defined by the device manufacturer. Some batteries are replaced too soon but most stay too long.

A portable system works well when the batteries are new but confidence drops after the first packs need replacing due to capacity fade. In time, the battery fleet becomes a jumble of good and bad batteries, and that’s when the headache begins. Battery management mandates that all batteries in a fleet are kept at an acceptable capacity level. Packs that fall below a given threshold must be replaced to keep system integrity. Battery failure occurs most often on a heavy traffic day or in an emergency when more than normal service is demanded.

Batteries exhibit human-like qualities and need good nutrition. Care begins by operating at room temperate and discharging them at a moderate current. There is some truth as to why batteries cared for by an individual user outperform those in a fleet; studies can back this up.

Charging is generally well understood, but the “ready” light is misconstrued. Ready does not mean “able.” There is no link to battery performance, nor does the green light promise full runtime. All batteries charge fully, even if weak; “ready” simply means that the battery is full.

The capacity a battery can hold diminishes with age and the charge time shortens with nickel-based batteries and in part also with lead acid, but not necessarily with Li-ion. Lower charge transfer capability that inhibits the flow of free electrons prolongs the charge time with aged Li-ion. (See BU-409a: Why do Old Li-ion Batteries Take Long to Charge?)

A short charging time propels faded batteries to the top, disguised as combat ready. System collapse is imminent when workers scramble for freshly charged batteries in an emergency; those that are lit-up may be deadwood. (Note that the charge time of a partially charged battery is also shorter.) Figure 1 shows the “ready” light that is known to lie.

Figure 1: The “ready” light lies. The READY light indicates that the battery is fully charged. This does not mean “able” as there is no link between “ready” and battery performance.

The amount of energy a battery can hold is measured in capacity. Capacity is the leading health indicator that determines runtime and predicts end of battery life when low. A new battery is rated at 100 percent, but few packs in service deliver the full amount: a workable capacity bandwidth is 80–100 percent. As a simple guideline, a battery on a two-way radio having a capacity of 100 percent would typically provide a runtime of 10 hours, 80 percent is 8 hours and 70 percent, 7 hours.

The service life of a battery is specified in number of cycles. Lithium- and nickel-based batteries deliver between 300 and 500 full discharge/charge cycles before the capacity drops below 80 percent.

Cycling is not the only cause of capacity loss; keeping a battery at elevated temperatures also induces stress. A fully charged Li-ion kept at 40°C (104°F) loses about 35 percent of its capacity in a year without being used. ( See BU:808: How to Prolong Lithium-based Batteries ). Ultra-fast chargers and harsh discharging is also harmful. This cuts battery life to half, and hobbyists can attest to this.

, ,

How to Prime Batteries

Himax - cycle-life-lead-acid（Data trend chart）

Discover what a battery needs to get going and maintain a long life.

In many ways, a battery behaves like a human being. It senses the kindness given and delivers on the care given. It is as if the battery has feelings and returns on the benevolence bestowed. But there are exceptions, as any parent raising a family will know; and the generosity conferred may not always deliver the anticipated returns.

To become a good custodian, you must understand the basic needs of a battery, a subject that is not taught in school. This section teaches what to do when the battery is new, how to feed it the right “food” and what to do when putting the pack aside for a while. Chapter 7 also looks into restrictions when traveling with batteries by air and how to dispose of them when their useful life has passed.

Just as a person’s life expectancy cannot be predicted at birth, neither can we date stamp a battery. Some packs live to a great old age while others die young. Incorrect charging, harsh discharge loads and exposure to heat are the battery’s worst enemies. Although there are ways to protect a battery, the ideal situation is not always attainable. This chapter discusses how to get the most from our batteries.

Priming a New Battery

Not all rechargeable batteries deliver the rated capacity when new, and they require formatting. While this applies to most battery systems, manufacturers of lithium-ion batteries disagree. They say that Li-ion is ready at birth and does not need priming. Although this may be true, users have reported some capacity gains by cycling after a long storage.

“What’s the difference between formatting and priming?” people ask. Both address capacities that are not optimized and can be improved with cycling. Formatting completes the fabrication process that occurs naturally during use when the battery is being cycled. A typical example is lead- and nickel-based batteries that improve with usage until fully formatted. Priming, on the other hand, is a conditioning cycle that is applied as a service to improve battery performance during usage or after prolonged storage. Priming relates mainly to nickel-based batteries.

Lead Acid

Formatting a lead acid battery occurs by applying a charge, followed by a discharge and recharge. This is done at the factory and is completed in the field as part of regular use. Experts advise not to strain a new battery by giving it heavy duty discharges at first but gradually working it in with moderate discharges, like an athlete trains for weight lifting or long-distance running. This, however, may not be possible with a starter battery in a vehicle and other uses. Lead acid typically reaches the full capacity potential after 50 to 100 cycles. Figure 1 illustrates the lifespan of lead acid.

cycle-life-lead-acid

Figure 1: Lifespan of Lead Acid
A new lead acid battery may not by fully formatted and only attains full performance after 50 or more cycles. Formatting occurs during use; deliberate cycling is not recommended as this would wear down the battery unnecessarily.

Deep-cycle batteries are at about 85 percent when new and will increase to 100 percent, or close to full capacity, when fully formatted. There are some outliers that are as low as 65 percent when tested with a battery analyzer. The question is asked, “Will these low-performers recover and stand up to their stronger brothers when formatted?” A seasoned battery expert said that “these batteries will improve somewhat but they are the first to fail.”

The function of a starter battery lies in delivering high load currents to crank the engine, and this attribute is present from the beginning without the need to format and prime. To the surprise of many motorists, the capacity of a starter battery can fade to 30 percent and still crank the engine; however, a further drop may get the driver stranded one morning. See also BU-904: How to Measure Capacity)

Nickel-based

Manufacturers advise to trickle charge a nickel-based battery for 16–24 hours when new and after a long storage. This allows the cells to adjust to each other and to bring them to an equal charge level. A slow charge also helps to redistribute the electrolyte to eliminate dry spots on the separator that might have developed by gravitation.

Nickel-based batteries are not always fully formatted when leaving the factory. Applying several charge/discharge cycles through normal use or with a battery analyzer completes the formatting process. The number of cycles required to attain full capacity differs between cell manufacturers. Quality cells perform to specification after 5–7 cycles, while lower-cost alternatives may need 50 or more cycles to reach acceptable capacity levels.

Lack of formatting causes a problem when the user expects a new battery to work at full capacity out of the box. Organizations using batteries for mission-critical applications should verify the performance through a discharge/charge cycle as part of quality control. The “prime” program of automated battery analyzers (Cadex) applies as many cycles as needed to attain full capacity.

Cycling also restores lost capacity when a nickel-based battery has been stored for a few months. Storage time, state-of-charge and temperature under which the battery is stored govern the ease of recovery. The longer the storage and the warmer the temperature, the more cycles will be required to regain full capacity. Battery analyzers help in the priming functions and assure that the desired capacity has been achieved.

Lithium-ion

Some battery users insist that a passivation layer develops on the cathode of a lithium-ion cell after storage. Also known as interfacial protective film (IPF), this layer is said to restrict ion flow, cause an increase in internal resistance and in the worst case, lead to lithium plating. Charging, and more effectively cycling, is known to dissolve the layer and some battery users claim to have gained extra runtime after the second or third cycle on a smartphone, albeit by a small amount.

Scientists do not fully understand the nature of this layer, and the few published resources on this subject only speculate that performance restoration with cycling is connected to the removal of the passivation layer. Some scientists outright deny the existence of the IPF, saying that the idea is highly speculative and inconsistent with existing studies. Whatever the outcome on the passivation of Li-ion may be, there is no parallel to the “memory” effect with NiCd batteries that require periodic cycling to prevent capacity loss. The symptoms may appear similar but the mechanics are different. Nor can the effect be compared to sulfation of lead acid batteries.

A well-known layer that builds up on the anode is the solid electrolyte solid electrolyte interface (SEI). SEI is an electrical insulation but has sufficient ionic conductivity to allow the battery to function normally. While the SEI layer lowers the capacity, it also protects the battery. Without SEI, Li-ion might not get the longevity that it has. (See BU-307: How does Electrolyte Work?)

The SEI layer develops as part of a formation process and manufacturers take great care to do this right, as a batched job can cause permanent capacity loss and a rise in internal resistance. The process includes several cycles, float charges at elevated temperatures and rest periods that can take many weeks to complete. This formation period also provides quality control and assists in cell matching, as well as observing self-discharge by measuring the cell voltage after a rest. High self-discharge hints to impurity as part of a potential manufacturing defect.

Electrolyte oxidation (EO) also occurs on the cathode. This causes a permanent capacity loss and increases the internal resistance. No remedy exists to remove the layer once formed but electrolyte additives lessen the impact. Keeping Li-ion at a voltage above 4.10V/cell while at an elevated temperature promotes electrolyte oxidation. Field observation shows that the combination of heat and high voltage can stress Li-ion more than harsh cycling.

Lithium-ion is a very clean system that does not need additional priming once it leaves the factory, nor does it require the level of maintenance that nickel-based batteries do. Additional formatting makes little difference because the maximum capacity is available right from the beginning, (the exception may be a small capacity gain after a long storage). A full discharge does not improve the capacity once the battery has faded — a low capacity signals the end of life. A discharge/charge may calibrate a “smart” battery but this does little to improve the chemical battery. (See BU-601: Inner Working of a Smart Battery.) Instructions recommending charging a new Li-ion for 8 hours are written off as “old school,” a left-over from the old nickel battery days.

Non-rechargeable Lithium

Primary lithium batteries, such as lithium-thionyl chloride (LTC), benefit from passivation in storage. Passivation is a thin layer that forms as part of a reaction between the electrolyte, the lithium anode and the carbon-based cathode. (Note that the anode of a primary lithium battery is lithium and the cathode is graphite, the reverse of Li-ion.)

Without this layer, most lithium batteries could not function because the lithium would cause a rapid self-discharge and degrade the battery quickly. Battery scientists even say that the battery would explode without the formation of lithium chloride layers and that the passivation layer is responsible for the battery’s existence and the ability to store for 10 years.

Temperature and state-of-charge promote the buildup of the passivation layer. A fully charged LTC is harder to depassivate after long storage than one that was kept at a low charge. While LTC should be stored at cool temperatures, depassivation works better when warm as the increased thermal conductivity and mobility of the ions helps in the process.

CAUTION Do not apply physical tension or excessive heat to the battery. Explosions due to careless handling have caused serious injuries to workers.

The passivation layer causes a voltage delay when first applying a load to the battery, and Figure 2 illustrates the drop and recovery with batteries affected by different passivation levels. Battery A demonstrates a minimal voltage drop while Battery C needs time to recover.

applying_load_passivated_battery

Figure 2: Voltage behavior when applying a load to a passivated battery.
Battery A has mild passivation, B takes longer to restore, and C is affected the most.
Courtesy EE Times

LTC in devices drawing very low current, such as a sensor for a road toll or metering, may develop a passivation layer that can lead to malfunction, and heat promotes such growth. This can often be solved by adding a large capacitor in parallel with the battery. The battery that has developed a high internal resistance is still capable of charging the capacitor to deliver the occasional high pulses; the standby time in between is devoted to recharging the capacitor.

To assist in sulfation prevention during storage, some lithium batteries are shipped with a 36kΩ resistor to serve as a parasitic load. The steady low discharge current prevents the layer from growing too thick, but this will reduce the storage life. After 2-year storage with the 36kΩ resistor, the batteries are said to still have 90 percent capacity. Another remedy is attaching a device that applies periodic discharge pulses during storage.

Not all primary lithium batteries recover when installed in a device and when a load is applied. The current may be too low to reverse the passivation. It is also possible that the equipment rejects a passivated battery as being low state-of-charge or defective. Many of these batteries can be prepared with a battery analyzer (Cadex) by applying a controlled load. The analyzer then verifies proper function before engaging the battery in the field.

The required discharge current for depassivation is a C-rate of 1C to 3C (1 to 3 times of the rated capacity). The cell voltage must recover to 3.2V when applying the load; the service time is typically 20 seconds. The process can be repeated but it should take no longer than 5 minutes. With a load of 1C, the voltage of a correctly functioning cell should stay above 3.0V. A drop to below 2.7V means end-of-life. (See BU-106: Primary Batteries)

These lithium-metal batteries have high lithium content and must follow more stringent shipping requirements than Li-ion of the same Ah. (See BU-704a: Shipping Lithium-based Batteries by air) Because of the high specific energy, special care must be taken in handling these cells.

CAUTION When charging an SLA with over-voltage, current limiting must be applied to protect the battery. Always set the current limit to the lowest practical setting and observe the battery voltage and temperature during charge.

In case of rupture, leaking electrolyte or any other cause of exposure to the electrolyte, flush with water immediately. If eye exposure occurs, flush with water for 15 minutes and consult a physician immediately.
Wear approved gloves when touching the electrolyte, lead and cadmium. On exposure to the skin, flush with water immediately.
, ,

How to Verify Sufficient Battery Capacity

Fade-Spare-Actual image（Data trend chart）

Know how to maintain a battery fleet and eliminate the risk of unexpected downtime.

A battery performs well when new but the capacity soon begins to fade with use and time. To assure reliable service during the life span of the battery, design engineers oversize the pack to include some spare capacity. This is similar to carrying extra fuel in an airplane to enable a waiting pattern or attempt a second landing approach when so required.

New batteries operate (should operate) at a capacity of 100 percent; replacement occurs when the packs fade to about 80 percent. All batteries must include a secure level of spare capacity to cover worst-case scenarios.

In addition to normal capacity fade, cold temperature lowers the capacity, especially Li-ion. The capacity loss of a Li-ion Energy Cell is about 17 percent at 0°C (32°F), 34 percent at –10°C (14°F) and 47 percent at –20°C (–4°F). Power Cells perform better at cold temperature with lower cold-related capacity losses than Energy Cells.

Lack of spare capacity is a common cause of system failures. This commonly happens during heavier than normal traffic or in an emergency. During routine operations, marginal batteries can hide comfortably among their peers, but they will fail when put to the test. A battery maintenance program as part of quality control assures that all batteries in the fleet are within the required performance range.

Figure 1 illustrates the breakdown of a battery that includes capacity fade and spare capacity. Adding 20 percent for fade and 20 percent for spare as a safety net leaves only 60 percent for the actual capacity. Such a generous allowance may not be practical in all cases.

Fade-Spare-Actual

Figure 1: Calculating spare battery capacity.
Spare capacity should be calculated for a worst-case scenario. The allowable capacity range is 80-100%; a spare capacity of 20 percent is recommended for critical use. Allow more capacity reserve when operating at cold temperature.

To verify sufficient spare capacity in a battery fleet, identify batteries that are close to retirement and spot-check their capacities after a busy day with a battery analyzer. The Cadex analyzer provides this function on the “Prime” program in that it applies a discharge before charge. The first reading on the display reflects the spare capacity and the second represents the full capacity after a charge.

If packs with fringe capacity levels come back from a full-day shift with less than 10 percent of spare capacity, raise the pass/fail target capacity from 80 to 85 percent to gain five extra points. If, on the other hand, these old-timers come back with 30 percent before charging, keep them longer by lowering the target capacity to, say, 70 percent. Knowing the energy needs for each application during a typical shift increases battery transparency. This improves reliability and creates a sweet spot between risk management and economics.

While most batteries are replaced when the capacity fades to 80 percent, scanners in some warehouses can be kept longer because they may not require all available capacity during an 8-hour shift. If this is the case, the target capacity can safely be set to 70 percent while maintaining ample spare capacity. A starter battery in a vehicle still cranks the motor with a capacity of 40 percent. The discharge is short and the battery recharges right away. Allowing the capacity to drop much further might prevent the battery from turning the engine on a cold morning, stranding the driver.

,

Discharging at High and Low Temperatures

Himax discharge-voltage-temperature（Data trend chart）

Explore the limitations when operating a battery at adverse temperatures and learn how to minimize the effects.

Like humans, batteries function best at room temperature. Warming a dying battery in a mobile phone or flashlight in our jeans might provide additional runtime due to improved electrochemical reaction. This is likely also the reason why manufacturers prefer to specify batteries at a toasty 27°C (80°F). Operating a battery at elevated temperatures improves performance but prolonged exposure will shorten life.

As all drivers in cold countries know, a warm battery cranks the car engine better than a cold one. Cold temperature increases the internal resistance and lowers the capacity. A battery that provides 100 percent capacity at 27°C (80°F) will typically deliver only 50 percent at –18°C (0°F). The momentary capacity-decrease differs with battery chemistry.

The dry solid polymer battery requires a temperature of 60–100°C (140–212°F) to promote ion flow and become conductive. This type of battery has found a niche market for stationary power applications in hot climates where heat serves as a catalyst rather than a disadvantage. Built-in heating elements keep the battery operational at all times. High battery cost and safety concerns have limited the application of this system. The more common lithium-polymer uses gelled electrolyte to enhance conductivity.

All batteries achieve optimum service life if used at 20°C (68°F) or slightly below. If, for example, a battery operates at 30°C (86°F) instead of a more moderate lower room temperature, the cycle life is reduced by 20 percent. At 40°C (104°F), the loss jumps to a whopping 40 percent, and if charged and discharged at 45°C (113°F), the cycle life is only half of what can be expected if used at 20°C (68°F).
The performance of all batteries drops drastically at low temperatures; however, the elevated internal resistance will cause some warming effect by efficiency loss caused by voltage drop when applying a load current. At –20°C (–4°F) most batteries are at about 50 percent performance level. Although NiCd can go down to –40°C (–40°F), the permissible discharge is only 0.2C (5-hour rate). Specialty Li-ion can operate to a temperature of –40°C but only at a reduced discharge rate; charging at this temperature is out of the question. With lead acid there is the danger of the electrolyte freezing, which can crack the enclosure. Lead acid freezes quicker with a low charge when the specific gravity is more like water than when fully charged.

Figure 1 illustrates the discharge voltage of an 18650 Li-ion under various temperatures. A 3A discharge of a 2.8Ah cell represents a C-rate of 1.07C. The reduced capacity at low temperature only applies while the cell is in that condition and will recover in room temperature.

discharge-voltage-temperature

Figure 1: Discharge voltage of an 18650 Li-ion cell at 3A and various temperatures.
Cell type: Panasonic NRC18650PD, 2.8Ah nominal, LiNiCoAlO2 (NCA)
Source: Technische Universität München (TUM)

Matched cells with identical capacities play an important role when discharging at low temperature and under heavy load. Since the cells in a battery pack can never be perfectly matched, a negative voltage potential can occur across a weaker cell in a multi-cell pack if the discharge is allowed to continue beyond a safe cut-off point. Known as cell reversal, the weak cell gets stressed to the point of developing a permanent electrical short. The larger the cell-count, the greater is the likelihood of cell-reversal under load. Over-discharge at a low temperature and heavy load is a large contributor to battery failure of cordless power tools.

The driving range of an electric vehicle between charges is calculated at ambient temperature. EV drivers are being made aware that frigid temperature reduces the available mileage. This loss is not only caused by heating the cabin electrically but by the inherent slowing of the battery’s electrochemical reaction, which reduces the capacity while cold.

,

Discharge Characteristics of Li-ion

Himax 18650 charge Data trend chart

Learn about the difference of energy and power requirements in a battery.

The early Li-ion battery was considered fragile and unsuitable for high loads. This has changed, and today lithium-based systems stand shoulder to shoulder with the robust nickel and lead chemistries. Two basic types of Li-ion have emerged: The Energy Cell and the Power Cell.

The performance of these two battery types is characterized by energy storage, also known as capacity, and current delivery, also known as loading or power. Energy and power characteristics are defined by particle size on the electrodes. Larger particles increase the surface area for maximum capacity and fine material decreases it for high power.

Decreasing particle size lowers the presence of electrolyte that fills the voids. The volume of electrolyte within the cell determines battery capacity. Decreasing the particle size reduces the voids between the particles, thereby lowering the electrolyte content. Too little electrolyte reduces ionic mobility and affects performance. Think of a drying felt pen that needs recuperating to keep marking papers.

Energy Cell

The Li-ion Energy Cell is made for maximum capacity to provide long runtimes. The Panasonic NCR18650B Energy Cell (Figure 1) has high capacity but is less enduring when discharged at 2C. At the discharge cutoff of 3.0V/cell, the 2C discharge produces only about 2.3Ah rather than the specified 3.2Ah. This cell is ideal for portable computing and similar light duties.

18650chargeDischarge-web

Figure 1: Discharge characteristics of NCR18650B Energy Cell by Panasonic.
The 3,200mAh Energy Cell is discharged at 0.2C, 0.5C, 1C and 2C. The circle at the 3.0V/cell line marks the end-of-discharge point at 2C.

Cold temperature losses:
25°C (77°F) = 100%
0°C (32°F) = ~83%
–10°C (14°F) = ~66%
–20°C (4°F) = ~53%
Source: Panasonic

Power Cell

The Panasonic UR18650RX Power Cell (Figure 2) has a moderate capacity but excellent load capabilities. A 10A (5C) discharge has minimal capacity loss at the 3.0V cutoff voltage. This cell works well for applications requiring heavy load current, such as power tools.


Figure 2: Discharge characteristics of UR18650RX Power Cell by Panasonic.
The 1950mAh Power Cell is discharged at 0.2C, 0.5C, 1C and 2C and 10A. All reach the 3.0V/cell cut-off line at about 2000mAh. The Power Cell has moderate capacity but delivers high current.

Cold temperature losses:
25°C (77°F) = 100%
0°C (32°F) = ~92%
–10°C (14°F) = ~85%
–20°C (4°F) = ~80%

Source: Panasonic

The Power Cell permits a continuous discharge of 10C. This means that an 18650 cell rated at 2,000mAh can provide a continuous load of 20A (30A with Li-phosphate). The superior performance is achieved in part by lowering the internal resistance and by optimizing the surface area of active cell materials. Low resistance enables high current flow with minimal temperature rise. Running at the maximum permissible discharge current, the Li-ion Power Cell heats to about 50ºC (122ºF); the temperature is limited to 60ºC (140ºF).

To meet the loading requirements, the pack designer can either use a Power Cell to meet the discharge C-rate requirement or go for the Energy Cell and oversize the pack. The Energy Cell holds about 50 percent more capacity than the Power Cell, but the loading must be reduced. This can be done by oversizing the pack, a method the Tesla EVs use. The battery achieves exceptional runtime but it gets expensive and heavy.

Discharge Signature

One of the unique qualities of nickel- and lithium-based batteries is the ability to deliver continuous high power until the battery is exhausted; a fast electrochemical recovery makes it possible. Lead acid is slower and this can be compared to a drying felt pen that works for short markings on paper and then needs rest to replenish the ink. While the recovery is relatively fast on discharge, and this can be seen when cranking the engine, the slow chemical reaction becomes obvious when charging. This only gets worse with age.

A battery may discharge at a steady load of, say, 0.2C as in a flashlight, but many applications demand momentary loads at double and triple the battery’s C-rating. GSM (Global System for Mobile Communications) for a mobile phone is such an example (Figure 3). GSM loads the battery with up to 2A at a pulse rate of 577 micro-seconds (μs). This places a large demand on a small battery; however, with a high frequency, the battery begins to behave more like a large capacitor and the battery characteristics change.


Figure 3: GSM discharge pulses of a cellular phone.
The 577 microsecond pulses drawn from the battery adjust to field strength and can reach 2 amperes.Courtesy of Cadex

In terms of longevity, a battery prefers moderate current at a constant discharge rather than a pulsed or momentary high load. Figure 4 demonstrates the decreasing capacity of a NiMH battery at different load conditions from a gentle 0.2C DC discharge, an analog discharge to a pulsed discharge. Most batteries follow a similar pattern in terms of load conditions, including Li-ion.


Figure 4: Cycle life of NiMH under different load conditions.
NiMH performs best with DC and analog loads; digital loads lower the cycle life. Li-ion behaves similarly.Source: Zhang (1998)

Figure 5 examines the number of full cycles a Li-ion Energy Cell can endure when discharged at different C-rates. At a 2C discharge, the battery exhibits far higher stress than at 1C, limiting the cycle count to about 450 before the capacity drops to half the level.


Figure 5: Cycle life of Li-ion Energy Cell at varying discharge levels.
The wear and tear of all batteries increases with higher loads. Power Cells are more robust than Energy Cells.Source: Choi et al (2002)

Simple Guidelines for Discharging Batteries

  • Heat increases battery performance but shortens life by a factor of two for every 10°C increase above 25–30°C (18°F above 77–86°F). Always keep the battery cool.
  • Prevent over-discharging. Cell reversal can cause an electrical short.
  • On high load and repetitive full discharges, reduce stress by using a larger battery.
  • A moderate DC discharge is better for a battery than pulse and heavy momentary loads.
  • A battery exhibits capacitor-like characteristics when discharging at high frequency. This allows higher peak currents than is possible with a DC load.
  • Nickel- and lithium-based batteries have a fast chemical reaction; lead acid is sluggish and requires a few seconds to recover between heavy loads.
  • All batteries suffer stress when stretched to maximum permissible tolerances.



, ,

Basics about Discharging

Himax - Discharge-Curves-Power（Data trend chart）

Learn how certain discharge loads will shorten battery life.

The purpose of a battery is to store energy and release it at a desired time. This section examines discharging under different C-rates and evaluates the depth of discharge to which a battery can safely go. The document also observes different discharge signatures and explores battery life under diverse loading patterns.

The electrochemical battery has the advantage over other energy storage devices in that the energy stays high during most of the charge and then drops rapidly as the charge depletes. The supercapacitor has a linear discharge, and compressed air and a flywheel storage device is the inverse of the battery by delivering the highest power at the beginning. Figures 1, 2 and 3 illustrate the simulated discharge characteristics of stored energy.

Discharge-Curves-Power

Most rechargeable batteries can be overloaded briefly, but this must be kept short. Battery longevity is directly related to the level and duration of the stress inflicted, which includes charge, discharge and temperature.

Remote control (RC) hobbyists are a special breed of battery users who stretch tolerance of “frail” high-performance batteries to the maximum by discharging them at a C-rate of 30C, 30 times the rated capacity. As thrilling as an RC helicopter, race car and fast boat can be; the life expectancy of the packs will be short. RC buffs are well aware of the compromise and are willing to both pay the price and to encounter added safety risks.

To get maximum energy per weight, drone manufacturers gravitate to cells with a high capacity and choose the Energy Cell. This is in contrast to industries requiring heavy loads and long service life. These applications go for the more robust Power Cell at a reduced capacity.

Depth of Discharge

Lead acid discharges to 1.75V/cell; nickel-based system to 1.0V/cell; and most Li-ion to 3.0V/cell. At this level, roughly 95 percent of the energy is spent, and the voltage would drop rapidly if the discharge were to continue. To protect the battery from over-discharging, most devices prevent operation beyond the specified end-of-discharge voltage.

When removing the load after discharge, the voltage of a healthy battery gradually recovers and rises towards the nominal voltage. Differences in the affinity of metals in the electrodes produce this voltage potential even when the battery is empty. A parasitic load or high self-discharge prevents voltage recovery.

A high load current, as would be the case when drilling through concrete with a power tool, lowers the battery voltage and the end-of-discharge voltage threshold is often set lower to prevent premature cutoff. The cutoff voltage should also be lowered when discharging at very cold temperatures, as the battery voltage drops and the internal battery resistance rises. Table 4 shows typical end-of-discharge voltages of various battery chemistries.

End-of-discharge

Nominal

Li-manganese

3.60V/cell

Li-phosphate

3.20V/cell

Lead acid

2.00V/cell

NiCd/NiMH

1.20V/cell
Normal load

Heavy load or
low temperature

3.0–3.3V/cell

2.70V/cell

2.70V/cell

2.45V/cell

1.75V/cell

1.40V/cell

1.00V/cell

0.90V/cell

Table 4: Nominal and recommended end-of-discharge voltages under normal and heavy load.

The lower end-of-discharge voltage on a high load compensates for the greater losses.

Over-charging a lead acid battery can produce hydrogen sulfide, a colorless, poisonous and flammable gas that smells like rotten eggs. Hydrogen sulfide also occurs during the breakdown of organic matter in swamps and sewers and is present in volcanic gases and natural gas. The gas is heavier than air and accumulates at the bottom of poorly ventilated spaces. Strong at first, the sense of smell deadens with time, and the victims are unaware of the presence of the gas. (See BU-703: Health Concerns with Batteries.)

What Constitutes a Discharge Cycle?

A discharge/charge cycle is commonly understood as the full discharge of a charged battery with subsequent recharge, but this is not always the case. Batteries are seldom fully discharged, and manufacturers often use the 80 percent depth-of-discharge (DoD) formula to rate a battery. This means that only 80 percent of the available energy is delivered and 20 percent remains in reserve. Cycling a battery at less than full discharge increases service life, and manufacturers argue that this is closer to a field representation than a full cycle because batteries are commonly recharged with some spare capacity left.



There is no standard definition as to what constitutes a discharge cycle. Some cycle counters add a full count when a battery is charged. A smart battery may require a 15 percent discharge after charge to qualify for a discharge cycle; anything less is not counted as a cycle. A battery in a satellite has a typical DoD of 30–40 percent before the batteries are recharged during the satellite day. A new EV battery may only charge to 80 percent and discharge to 30 percent. This bandwidth gradually widens as the battery fades to provide identical driving distances. Avoiding full charges and discharges reduces battery stress. (See also BU-1003: Electric Vehicle.)



A hybrid car only uses a fraction of the capacity during acceleration before the battery is recharged. Cranking the motor of a vehicle draws less than 5 percent energy from the starter battery, and this is also called a cycle in the automotive industry. Reference to cycle count must be done in context with the respective duty.



Reference to discharge cycle or cycle count does not relate equally well to all battery applications. One example where counting discharge cycles does not reflect state-of-life accurately is in a storage device (ESS). These batteries supplement renewable energies from wind power and photovoltaic by delivering short-term energy when needed and storing if in excess. The time duration between charge and discharged can be in milliseconds; a typical battery state-of-charge is 40–60%. Rather than cycle count, coulomb counting may be used as a means of measuring wear and tear.

,

Charging at High and Low Temperatures

Low Temperatures Article illustrations

Learn how to extend battery life by moderating ambient temperatures.

Batteries operate over a wide temperature range, but this does not give permission to also charge them at these conditions. The charging process is more delicate than discharging and special care must be taken. Extreme cold and high heat reduce charge acceptance, so the battery must be brought to a moderate temperature before charging.

Older battery technologies, such as lead acid and NiCd, have higher charging tolerances than newer systems. This allows them to charge below freezing but at a reduced charge C-rate. When it comes to cold-charging NiCd is hardier than NiMH.

Table 1 summarizes the permissible charge and discharge temperatures of common rechargeable batteries. The table excludes specialty batteries that are designed to charge outside these parameters.

Battery type

Charge temperature

Discharge temperature

Charge advisory

Lead acid

 –20°C to 50°C
(–4°F to 122°F)		 –20°C to 50°C
(–4°F to 122°F)		 Charge at 0.3C or lessbelow freezing.
Lower V-threshold by 3mV/°C when hot.

NiCd, NiMH

 0°C to 45°C
(32°F to 113°F)		 –20°C to 65°C
(–4°F to 149°F)		 Charge at 0.1C between –18°C and 0°C.

Charge at 0.3C between 0°C and 5°C.
Charge acceptance at 45°C is 70%. Charge acceptance at 60°C is 45%.

Li-ion

 0°C to 45°C
(32°F to 113°F)		 –20°C to 60°C
(–4°F to 140°F)		 No charge permitted below freezing.
Good charge/discharge performance at higher temperature but shorter life.

Table 1: Permissible temperature limits for various batteries. Batteries can be discharged over a large temperature range, but the charge temperature is limited. For best results, charge between 10°C and 30°C (50°F and 86°F). Lower the charge current when cold.

Low-temperature Charge

Fast charging of most batteries is limited to 5°C to 45°C (41°F to 113°F); for best results consider narrowing the temperature bandwidth to between 10°C and 30°C (50°F and 86°F) as the ability to recombine oxygen and hydrogen diminishes when charging nickel-based batteries below 5°C (41°F). If charged too quickly, pressure builds up in the cell that can lead to venting. Reduce the charge current of all nickel-based batteries to 0.1C when charging below freezing.

Nickel-based chargers with NDV full-charge detection offer some protection when fast charging at low temperatures; the poor charge acceptance when cold mimics a fully charged battery. This is in part caused by a high pressure buildup due to the reduced ability to recombine gases at low temperature. Pressure rise and a voltage drop at full charge appear synonymous.

To enable fast charging at all temperatures, some industrial batteries add a thermal blanket that heats the battery to an acceptable temperature; other chargers adjust the charge rate to prevailing temperatures. Consumer chargers do not have these provisions and the end user is advised to only charge at room temperature.

Lead acid is reasonably forgiving when it comes to temperature extremes, as the starter batteries in our cars reveal. Part of this tolerance is credited to their sluggish behavior. The recommended charge rate at low temperature is 0.3C, which is almost identical to normal conditions. At a comfortable temperature of 20°C (68°F), gassing starts at charge voltage of 2.415V/cell. When going to –20°C (0°F), the gassing threshold rises to 2.97V/cell.

A lead acid battery charges at a constant current to a set voltage that is typically 2.40V/cell at ambient temperature. This voltage is governed by temperature and is set higher when cold and lower when warm. Figure 2 illustrates the recommended settings for most lead acid batteries. In parallel, the figure also shows the recommended float charge voltage to which the charger reverts when the battery is fully charged. When charging lead acid at fluctuating temperatures, the charger should feature voltage adjustment to minimize stress on the battery. (See also BU-403: Charging Lead Acid.)


Figure 2: Cell voltages on charge and float at various temperatures.
Charging at cold and hot temperatures requires adjustment of voltage limit.

Freezing a lead acid battery leads to permanent damage. Always keep the batteries fully charged because in the discharged state the electrolyte becomes more water-like and freezes earlier than when fully charged. According to BCI, a specific gravity of 1.15 has a freezing temperature of –15°C (5°F). This compares to –55°C (–67°F) for a specific gravity of 1.265 with a fully charged starter battery. Flooded lead acid batteries tend to crack the case and cause leakage if frozen; sealed lead acid packs lose potency and only deliver a few cycles before they fade and need replacement.

Li ion can be fast charged from 5°C to 45°C (41 to 113°F). Below 5°C, the charge current should be reduced, and no charging is permitted at freezing temperatures because of the reduced diffusion rates on the anode. During charge, the internal cell resistance causes a slight temperature rise that compensates for some of the cold. The internal resistance of all batteries rises when cold, prolonging charge times noticeably.

Many battery users are unaware that consumer-grade lithium-ion batteries cannot be charged below 0°C (32°F). Although the pack appears to be charging normally, plating of metallic lithium can occur on the anode during a sub-freezing charge. This is permanent and cannot be removed with cycling. Batteries with lithium plating are more vulnerable to failure if exposed to vibration or other stressful conditions. Advanced chargers (Cadex) prevent charging Li-ion below freezing.

Advancements are being made to charge Li-ion below freezing temperatures. Charging is indeed possible with most lithium-ion cells but only at very low currents. According to research papers, the allowable charge rate at –30°C (–22°F) is 0.02C. At this low current, the charge time would stretch to over 50 hours, a time that is deemed impractical. There are, however, specialty Li-ions that can charge down to –10°C (14°F) at a reduced rate.

High-temperature Charge

Heat is the worst enemy of batteries, including lead acid. Adding temperature compensation on a lead acid charger to adjust for temperature variations is said to prolong battery life by up to 15 percent. The recommended compensation is a 3mV drop per cell for every degree Celsius rise in temperature. If the float voltage is set to 2.30V/cell at 25°C (77°F), the voltage should read 2.27V/cell at 35°C (95°F). Going colder, the voltage should be 2.33V/cell at 15°C (59°F). These 10°C adjustments represent 30mV change.

Table 3 indicates the optimal peak voltage at various temperatures when charging lead acid batteries. The table also includes the recommended float voltage while in standby mode.

BATTERY STATUS -40°C (-40°F) -20°C (-4°F) 0°C (32°F) 25°C (77°F) 40°C (104°F)
Voltage limit
on recharge		 2.85V/cell 2.70V/cell 2.55V/cell 2.45V/cell 2.35V/cell
Float voltage
at full charge		 2.55V/cell
or lower		 2.45V/cell
or lower		 2.35V/cell
or lower		 2.30V/cell
or lower		 2.25V/cell
or lower

Table 3: Recommended voltage limits when charging and maintaining stationary lead acid batteries on float charge. Voltage compensation prolongs battery life when operating at temperature extremes.

Charging nickel-based batteries at high temperatures lowers oxygen generation, which reduces charge acceptance. Heat fools the charger into thinking that the battery is fully charged when it’s not.

Charging nickel-based batteries when warm lowers oxygen generation that reduces charge acceptance. Heat fools the charger into thinking that the battery is fully charged when it’s not. Figure 4 shows a strong decrease in charge efficiency from the “100 percent efficiency line” when dwelling above 30°C (86°F). At 45°C (113°F), the battery can only accept 70 percent of its full capacity; at 60°C (140°F) the charge acceptance is reduced to 45 percent. NDV for full-charge detection becomes unreliable at higher temperatures, and temperature sensing is essential for backup.

Figure 4: NiCd charge acceptance as a function of temperature. High temperature reduces charge acceptance and departs from the dotted “100% efficiency line.” At 55°C, commercial NiMH has a charge efficiency of 35–40%; newer industrial NiMH attains 75–80%.

Lithium-ion performs well at elevated temperatures but prolonged exposure to heat reduces longevity. Charging and discharging at elevated temperatures is subject to gas generation that might cause a cylindrical cell to vent and a pouch cell to swell. Many chargers prohibit charging above 50°C (122°F).

Some lithium-based packs are momentarily heated to high temperatures. This applies to batteries in surgical tools that are sterilized at 137°C (280°F) for up to 20 minutes as part of autoclaving. Oil and gas drilling as part of fracking also exposes the battery to high temperatures.

Capacity loss at elevated temperature is in direct relationship with state-of-charge (SoC). Figure 5 illustrates the effect of Li-cobalt (LiCoO2) that is first cycled at room temperature (RT) and then heated to 130°C (266°F) for 90 minutes and cycled at 20, 50 and 100 percent SoC. There is no noticeable capacity loss at room temperature. At 130°C with a 20 percent SoC, a slight capacity loss is visible over 10 cycles. This loss is higher with a 50 percent SoC and shows a devastating effect when cycled at full charge.

Figure 5: Capacity loss at room temperature (RT) and 130°C for 90 minutes
Sterilization of batteries for surgical power tools should be done at low SoC.

Test: LiCoO2/Graphite cells were exposed to 130°C for 90 min.at different SoC between each cycle.
