Custom LiPO 362828 3.7V 240mAh Battery for Electronic & Consumer Devices

LiPO 362828 3.7V 240mAh battery supplier

Product Model: LiPO-362828-3.7V-240mAh

High Discharge, Custom Solutions:

Himax LiPo batteries deliver superior high discharge rates, ideal for drones, RC vehicles, and more. We offer custom battery packs and bulk orders with competitive wholesale pricing and fast global shipping to meet your specific needs.

Product Description:

Built-in PCM + NTC

Built-in PCM using Seiko IC support 2C continuous current; Has 10KΩ NTC for temperature protection.

40mm length external cables

Red for positive cable, Black for negative cable, Yellow for NTC cable.

Customize connector

Using JST-PH-3P connector.

Technical Parameters:

Part Number	LiPO-362828-3.7V-240mAh
MAIN PARAMETER
Rated Capacity	240mAh
Nominal Voltage	3.7V
Max Charge Voltage	4.2V
Discharge Cut Off Voltage	2.75V
Charging Current	≤1C
Max. Continuous Discharging Current	2C
Cycle Life	300 cycles at 100% DOD
Discharge Rate	2C
MECHANICAL SPECIFICATIONS
Dimensions (TWH)	3.628.531mm
Weight	5.3g
Encapsulation	Aluminum plastic film/heat shrink PVC
OTHERS
Operating Temperature	Charge : 0℃-45℃ Discharge : -20℃-60℃
Storage Temperature	-10°C~45°C
Humidity	65±20%
Certification
Main protection function	Over charge,Over discharge, Over current, Short circuit etc.
Delivery period	Depend on order quantities
Warranty	1 year since the date of shipping
APPLICATIONS
Electronic, consumer product, headset etc.

FAQ

Frequently Asked Questions (FAQs)

What applications suit the 3.7V 240mAh LiPo battery?

This micro battery is ideal for wearables, Bluetooth headsets, IoT sensors, medical patches, smart cards, and other space-constrained devices.

How small is the 362828 LiPo cell?

With dimensions of approximately 3.6mm × 28mm × 28mm, this battery fits into extremely compact enclosures while delivering 240mAh capacity.

Is the 240mAh LiPo battery rechargeable and safe?

Yes. The battery is fully rechargeable and includes PCM protection against over-charge, over-discharge, over-current, and short circuits.

Can you customize the connector and wire length for this battery?

Certainly. We offer JST, Molex, and custom connectors with configurable wire lengths to match your device’s assembly requirements.

What is the maximum discharge rate for the 362828 battery?

The battery supports 1C continuous discharge (240mA) and can handle higher pulse currents depending on PCM configuration.

Download

Custom LiPo Battery

Customization Process & Requirements

Customization Process

Step 1 – Specification Confirmation

Provide your target capacity (adjustable around 240mAh), voltage, maximum dimensions, discharge rate, and connector preferences.

Step 2 – Technical Feasibility Assessment

Our team reviews the request and recommends the optimal cell chemistry and PCM settings for your micro-device application.

Step 3 – Prototype Sample Production

We deliver functional samples within 7–12 working days for your testing and integration.

Step 4 – Validation & Iteration

You test the samples in your application. We refine dimensions, connectors, or protection parameters as needed.

Step 5 – Production & Fulfillment

After final approval, we proceed with mass production, QC inspection, and global delivery.

Customization Requirements

Ultra-compact form factors available
Low minimum order quantities for prototype and small-batch production
Custom PCM thresholds for application-specific safety
Wire harness and connector customization
RoHS/REACH compliant materials

Kindly Reminders: • Production time: 10 to 15 days for samples; 25 to 30 days for bulk orders. • Transportation methods: By couriers, air, truck, sea. • Payment terms: TT/PayPal/Assurance order.
