Custom LIPO 702346 3.7V 1500mAh Battery Pack for Smart AI & Portable Devices

Custom 3.7V 1.5Ah 702346 LIPO battery for Smart AI Portable Devices

Product Model: LIPO 702346 3.7V 1500mAh

High Discharge, Custom Solutions:

Himax LiPo batteries deliver superior high discharge rates, ideal for drones, RC vehicles, and more. We offer custom battery packs and bulk orders with competitive wholesale pricing and fast global shipping to meet your specific needs.

Product Description:

Wide Applications Use

The 3.7V 1500mAh 702346 LiPo battery is ideal for various devices, including smart wearables, wireless audio equipment, portable medical devices, and Iot products like GPS trackers and smart sensors etc.

High-performance

With a capacity of 1500mAh and a compact 702346 size, this battery provides stable and long-lasting power. It delivers consistent performance, ensuring reliability for devices requiring high energy density and lightweight power sources.

Eco-Friendly Design

Built with high-quality LiPo technology, the battery features overcharge, over-discharge, and short-circuit protection. Its environmentally friendly design ensures compliance with safety and sustainability standards, making it a dependable choice for modern electronic devices.

Technical Parameters:

Part Number	LIPO-702346-3.7V 1500mAh
MAIN PARAMETER
Rated Capacity	1500mAh
Nominal Voltage	3.7V
Max Charge Voltage	4.2V
Discharge Cut Off Voltage	3.0V
Charging Current	≤1C
Max. Continuous Discharging Current	1.5A
Cycle Life	300 cycles at 100% DOD
Discharge Rate	1C
MECHANICAL SPECIFICATIONS
Dimensions (TWH)	Max 7.023.550mm
Weight	Approx 30g
Encapsulation	Aluminum plastic film/heat shrink PVC
OTHERS
Operating Temperature	Charge : 0℃-45℃ Discharge : -20℃-60℃
Storage Temperature	-10°C~45°C
Humidity	65±20%
Certification	REACH/ROHS
Main protection function	Over charge,Over discharge, Over current, Short circuit etc.
Delivery period	Depend on order quantities
Warranty	1 year since the date of shipping
APPLICATIONS
Smart AI devices, Portable medical devices and Power toys etc

FAQ

Frequently Asked Questions (FAQs)

What applications is the 3.7V 1500mAh LiPo battery designed for?

This battery suits smart wearables, wireless audio equipment, portable medical devices, GPS trackers, smart sensors, and power toys.

What makes the 702346 LiPo cell suitable for smart AI devices?

Its 1500mAh capacity and compact 7.0×23.5×50mm dimensions provide stable, long-lasting power for devices requiring high energy density.

Does the 1500mAh battery include safety protection?

Yes. The battery features overcharge, over-discharge, and short-circuit protection, with REACH and RoHS compliance for environmental safety.

Can the 702346 battery be customized for specific voltage or capacity needs?

Absolutely. We offer capacity adjustments, dimension modifications, connector changes, and PCM parameter customization.

What is the maximum continuous discharge current for this battery?

The battery supports a maximum continuous discharge current of 1.5A, with a 1C discharge rate and 300-cycle life at 100% DOD.

Download

Custom LiPo Battery

Customization Process & Requirements

Customization Process

Step 1 – Requirement Gathering

Share your target voltage, capacity, dimensions, discharge requirements, and application environment.

Step 2 – Engineering Evaluation

Our engineers assess technical feasibility and propose the optimal cell and PCM configuration.

Step 3 – Sample Development

We produce samples for your testing. Lead time is typically 10–15 working days for custom specifications.

Step 4 – Testing & Validation

Samples are tested for capacity, cycle life, safety, and environmental performance. You approve before production.

Step 5 – Production & Delivery

Mass production begins with strict quality control. We provide global shipping and after-sales support.

Customization Requirements

Custom capacity and dimension options
Connector and wire harness customization
PCM parameter configuration for specific safety needs
REACH/RoHS certification
Flexible MOQ for pilot and mass production

Kindly Reminders: • Production time: 10 to 15 days for samples; 25 to 30 days for bulk orders. • Transportation methods: By couriers, air, truck, sea. • Payment terms: TT/PayPal/Assurance order.
